Dreadbox Abyss 4 Voice Analog Synthesizer

Features:

• 1 VCO + 1 Sub Oscillator per Voice
• White Noise Generator
• Independent Wave shaping Modulator
• Polyphonic Glide function
• 4 independent LFOs (1 for each voice) to control Vibrato
• Variable Speed Depth and Delay
• Vibratos can be set out of phase via the Detune (Vibrato) control
• VCO autotune function
• 24 dB/oct 4-pole Resonating Low Pass Filter (based on the Murmux series)
• Dedicated ADSR Envelope Generator to the Filter
• Velocity sensitivity over the EG Attack Rate or the EG Level
• Dedicated ADSR Envelope Generator to the VCA
• OTA Drive circuit
• Reflector: 1024 BBD Delay for Chorus/Flanger or Static Flangers
• Hybrid Delay Circuit as found on the Erebus
• 4-stage Analog Phase Shifter
• 2 Analog LFOs with 4 waves each to control the Filter, Reflector, Delay, Phaser
• 4 Modulation Wheel Choices
• Fine Tune Control
• CV Control over Filter, Phaser, Delay and Reflector
• Dry output (without effects)
• Signal Input ( at the effect stage)
• MIDI In / MIDI Through
• Aluminum Case
