The Avedis Audio E27 is one of the coolest and most unique EQ's on the market. A completely discrete design, and specifically for the 500 series format, it features 3 bands of EQ with 9 selectable frequencies per band. Push button shelving for low and high frequencies, allows for more flexibility. Jensen transformer balanced input & outputs, and gold plated rotary switches and 15-way connector provide for great sound & long life.
The level knob controls up to 16 db's of cut and boost but for those who only need a few db's, the travel of the pot starts slow and speeds up at the extremes giving the user more fine control at levels of 6 db's or less. Knob positions are not only easy to see from a distance but are also felt - the level pot knob has a small point so you know where you are without looking at the eq. The outer frequency control knob has a knurl texture for easy grip.
Features:
The level knob controls up to 16 db's of cut and boost but for those who only need a few db's, the travel of the pot starts slow and speeds up at the extremes giving the user more fine control at levels of 6 db's or less. Knob positions are not only easy to see from a distance but are also felt - the level pot knob has a small point so you know where you are without looking at the eq. The outer frequency control knob has a knurl texture for easy grip.
Features:
- Standard 500 series modular size 1.5" x 5.25"
- 3-bands with 9 selectable frequencies per band
- ±16 dB of boost and cut using continuous variable potentiometer
- Push button shelving option for low and high frequencies
- All discrete design
- High headroom
- Low noise
- Jensen transformers couple the input & output
- Custom machined aluminum knobs
- Gold plated rotary switches and 15-way connector for long life
- Utilizes 1122 opamps
- 80ma current draw total, 40 per rail
